Corflute Protection BoardVendor:
Corflute Protection Board is a lightweight 2mm corrugated polypropylene sheet for protecting waterproofing membranes and suitable finished surfaces while other construction work is taking place. Each sheet measures 1805mm × 1210mm and is easy to cut and position on site.Choose Corflute where freshly installed...- From $7.41
- From $7.41
- Unit price
- per
-
30mm HexCell Wall Drainage Cell - Standard Duty 550Vendor:Drainage CellA 30mm studded drainage cell that goes behind retaining walls, planter boxes, green roofs, and below-grade walls. The studs form a void that carries water down to the drain instead of letting it sit against the structure, and the sheet doubles as a protection...
- $38.46
- $38.46
- Unit price
- per
-
Terrafix Geo Textile 2m WideVendor:Soil FilterTo stabilise coastal structures, protect landfill lining systems, and reinforce ground in the road, water, coastal, and waste sectors, Terrafix Geo Textile 2m Wide (Texcel R) provides a high-elongation barrier that minimises installation damage and maintains close soil contact. This non-woven staple fibre geotextile...
- From $4.13
- From $4.13
- Unit price
- per
Frequently Asked Questions
Why protect a cured membrane?
Once a below-grade membrane is on, the next trade backfills, casts concrete or fixes materials against it. Without a protection layer, that work can puncture or score the membrane and cause a leak that is costly to reach and fix.
What is a protection board?
A rigid board placed over the cured membrane to resist impact and puncture during backfill and slab work. Corflute protection board is the stocked product. It goes on retaining walls, planter boxes and below-grade slabs.
What is the difference between a protection board and a drainage cell?
A protection board resists impact. A drainage cell creates a void that lets water drain away from the structure. They do different jobs and are often used together on below-grade walls.
Where is a geotextile used?
Between the drainage cell and the soil. It stops fine particles from clogging the drainage void. It goes against the drainage cell in below-grade wall and sub-surface drainage assemblies.
Do internal wet-area jobs need a protection layer?
No. Internal wet-area membranes are protected by the tile finish. Protection boards and drainage cells are for below-grade and buried membranes. Match the product spec to the job conditions before you start.
