Lauxes Grates NeXT Generation NXT35 Linear Drain Kit is a heavy-duty anodised aluminium drainage system designed for high-traffic driveways, commercial entryways, and salt-exposed pool zones. Featuring a 10.3-tonne load rating and integrated anti-tracking technology, this modular kit prevents surface water runoff and structural subsidence while maintaining a corrosion-proof finish in harsh coastal environments.
The system complies with Australian Class B light traffic standards and includes UV-stable components to ensure long-term integrity under intense sun exposure without cracking or fading.
Frequently Asked Questions About NeXT Generation 35 Aluminium Outdoor Drainage Grate
Q: Can I cut the 5.6m grate to fit shorter lengths?
A: Yes, the NeXT Generation 35 grate can be easily cut onsite using a mitre saw with a suitable blade. This allows custom fitting for patios, pools, and landscaping jobs.
Q: How do I connect multiple lengths together?
A: Use Lauxes joiners to securely connect multiple sections. This creates seamless linear drainage runs without loss of performance.
Q: Is it suitable for driveways with car traffic?
A: Absolutely. With a 10.3 tonne load rating, the grate can handle regular vehicular traffic including cars and small trucks.
Q: Will it rust over time in coastal areas?
A: No, it’s made from anodised aluminium and comes with a lifetime rustproof warranty—ideal for coastal and salt-exposed environments.
Q: How is cleaning performed?
A: Simply lift out the grate to access the tray below. Debris can be flushed or vacuumed out, and the unit reinstalled without tools.
Use NeXT Generation 35 Aluminium Outdoor Drainage Grate for:
- Pool surrounds – fast drainage and corrosion resistance
- Driveways – heavy-duty support under wheel loads
- Patios and decks – no water pooling or surface tracking
- Commercial entryways – professional finish and easy cleaning
Why Use NeXT Generation 35 Aluminium Outdoor Drainage Grate for:
- Reduces maintenance and prevents long-term water damage
- Provides flexible design and fast installation
- Backed by a lifetime rustproof guarantee for total peace of mind
How to apply NeXT Generation 35 Aluminium Outdoor Drainage Grate:
- Measure and mark your desired drainage length on site
- Use a mitre saw to cut the aluminium grate to length if needed
- Position the tray over prepared bedding or drainage trench
- Install Lauxes joiners for multi-length assemblies
- Fix waste outlet at any point on the tray to suit your drainage plan
- Secure grate into tray and test flow with water
NeXT Generation 35 Aluminium Outdoor Drainage Grate limitations:
- Not suitable for low-profile indoor applications due to 35mm depth
- Not designed for decorative finishes where visual discretion is key
Safety precautions when using NeXT Generation 35 Aluminium Outdoor Drainage Grate:
- Personal Protective Equipment: Use gloves and eye protection when cutting aluminium onsite
- Ventilation: Not required for mechanical installation
- Handling: Avoid scratching anodised surface during transport and cutting
- First Aid: Standard wound care in case of sharp edge contact; aluminium is non-toxic
NeXT Generation 35 Aluminium Outdoor Drainage Grate can be used on the following substrates:
- Concrete – fixed with appropriate bedding and drainage outlet
- Asphalt – embedded with edge protection for heavy load stability
- Pavers – set between modular stones with secure anchoring
- Tiles – positioned with tile adhesive or screed base for clean finish
