Use Autoshield NP60 for: Rapid and compliant windscreen replacements, side glass bonding on standard and specialised aluminium bodies, and any application demanding high green strength for minimal vehicle downtime.
Autoshield NP60: A Technical Overview
Autoshield NP60 is a one-component, moisture-curing polyurethane adhesive engineered for structural windscreen bonding. Its high-modulus formulation cures rapidly to form a tough, yet highly flexible seal, providing superior bond strength and rigidity. The chemistry is specifically designed to achieve a rapid build in shear strength, enabling a 1-hour safe drive-away time, even in vehicles equipped with dual airbags. This performance is critical for automotive workshops focused on maximising throughput without compromising on safety or quality.
System Integration & Interoperability Analysis
Autoshield NP60 is engineered to function as an integral component of a vehicle's structural system. A correctly bonded windscreen contributes significantly to the torsional rigidity of the chassis and is critical for the correct deployment of passenger-side airbags. This adhesive’s high modulus properties ensure it restores the vehicle's structural integrity to OEM specifications. Its specific suitability for aluminium bodies makes it a vital tool for repairing and manufacturing modern vehicles where mixed materials are common. Crucial Note: To ensure predictable curing and bond performance, do not apply Autoshield NP60 in the presence of, or onto, uncured silicone or hybrid (MS, SPUR, STPE) sealants, as this will cause bond failure.
Failure Mode & Effects Analysis (FMEA)
Understanding how a product prevents failure is critical in safety-focused applications. Autoshield NP60's specifications directly mitigate common failure modes:
-
Failure Mode: Adhesive bond failure during a frontal collision.
Effect: Compromised cabin integrity, airbag malfunction, potential occupant ejection.
Prevention Specification: Autoshield NP60 passes the rigorous FMVSS 212 crash test. Its ability to develop high shear strength quickly ( >3 MPa within 5 hours) ensures the windscreen is retained under impact forces, providing the necessary support for airbag function just 60 minutes after installation. -
Failure Mode: Gradual bond degradation from environmental exposure (UV, moisture, road salt).
Effect: Water leaks, wind noise, whistling, and a progressive loss of structural contribution.
Prevention Specification: The product exhibits excellent resistance to water and salt spray. The specified application protocol—involving primers for plain glass or slight abrasion of ceramic bands—ensures the bond line is shielded from UV radiation and that a tenacious, long-term bond is achieved, preventing environmental ingress and maintaining performance over the vehicle's life.
Core Features & Specifications
- 1-Hour Drive-Away Time: Achieves safe drive-away strength in 60 minutes for vehicles with dual airbags, verified by FMVSS 212 crash testing.
- High Modulus Performance: Delivers a final shear strength of over 3.5 MPa, contributing to the vehicle's torsional rigidity and structural integrity.
- Exceptional Flexibility: With over 700% elongation at break, it easily accommodates vibration and differential thermal expansion between the glass and vehicle body, preventing stress fractures.
- Primerless Adhesion: Bonds directly to clean, prepared ceramic frit bands, saving significant application time and reducing process complexity.
- Wide Service Temperature Range: Performs reliably from -40°C to +90°C, making it suitable for all Australian climate conditions, from alpine winters to tropical summers.
- High Green Strength: The adhesive's initial tack and viscosity prevent glass slippage after placement, ensuring accurate positioning without the need for extensive taping.
The Autoshield NP60 Advantage
- Maximise Workshop Throughput: The certified 1-hour drive-away time allows for more jobs per day, directly increasing workshop revenue and customer satisfaction.
- Ensure Safety Compliance: Adherence to the FMVSS 212 standard provides documented proof of a safe installation, mitigating liability for repairers.
- Deliver a Structural Repair: Re-establishes the windscreen as a structural component, restoring the vehicle's handling dynamics and crash performance to OEM levels.
- Accommodate Body Flex & Vibration: The combination of high tear strength (approx. 20 N/mm) and massive elongation capacity ensures the bond withstands the toughest road conditions without failing.
- Optimised for Modern Vehicles: Specifically formulated for excellent performance on both traditional steel and modern aluminium vehicle bodies.
Applications in Practice: Trade Scenarios
For Automotive Glaziers: Urgent Windscreen Replacement
The Engineering Challenge: A customer requires an urgent windscreen replacement on a late-model SUV with dual airbags. The core challenge is minimising vehicle downtime while ensuring the replacement meets stringent Australian Design Rule (ADR) and OEM safety requirements for airbag deployment.
The System-Based Solution with Autoshield NP60: The rapid cure chemistry of NP60 enables a certified 1-hour safe drive-away time. This allows the glazier to complete the job, perform final checks, and return the vehicle to the owner in a fraction of the time required by standard adhesives, dramatically increasing workshop efficiency and job turnover.
Best Practice Note: For optimal performance in colder weather (between 5°C and 15°C), precondition the cartridge to approximately 20°C before use and double the specified drying times for any required primers to ensure a full-strength bond.
For Specialty Vehicle & Caravan Builders: Aluminium Frame Glazing
The Engineering Challenge: Bonding large windscreens and side-glass panels into extruded aluminium frames on a new caravan or custom truck body. The challenge lies in achieving a durable, weatherproof bond that can accommodate the significant difference in thermal expansion coefficients between glass and aluminium.
The System-Based Solution with Autoshield NP60: NP60 is specifically engineered for excellent adhesion to aluminium substrates. Its >700% elongation capacity absorbs the shear stress generated by differential movement, preventing bond failure and stress cracks in the glass. The high modulus and excellent weather resistance ensure a permanent, leak-proof structural seal.
Best Practice Note: Ensure all aluminium bonding surfaces are meticulously cleaned with acetone in a single pass using a fresh, lint-free cloth. This removes any residual processing oils or oxides, which are critical for achieving a reliable, long-term bond.
Certifications & Regulatory Compliance
FMVSS 212 (Federal Motor Vehicle Safety Standard 212): This product passes this critical US safety standard for windscreen retention. Its relevance for Australian trades is paramount; it demonstrates that Autoshield NP60 has the bond strength to keep a windscreen in place during a 48 km/h frontal collision. This is essential for ensuring passenger-side airbags deploy correctly against the windscreen and for preventing occupant ejection, aligning with the core safety principles of Australian Design Rules.
Storage & Shelf Life Considerations
For optimal performance and to ensure product reliability, store Autoshield NP60 cartridges in a cool, dry location, protected from direct sunlight and moisture. The product has a guaranteed shelf life of twelve months from the date of shipment when stored under these conditions.
Comparative Performance Overview
| Metric | Autoshield NP60 | Standard PU Adhesive | Advantage |
|---|---|---|---|
| Safe Drive-Away Time (Dual Airbag) | 1 Hour | 4-8 Hours | Significantly increases workshop throughput and profitability by reducing vehicle downtime by over 75%. |
| Elongation at Break | >700% | ~400-500% | Superior flexibility allows the bondline to absorb higher levels of vibration and thermal stress, preventing cohesive failure over the vehicle's lifespan. |
| Shear Strength (after 5 hours) | >3 MPa | <1 MPa | The rapid development of structural strength is the key engineering property that enables the 1-hour drive-away time and ensures early safety compliance. |
| Tear Strength | ~20 N/mm | ~9-12 N/mm | Higher resistance to tearing under load, providing a more robust and damage-tolerant bond, especially in high-stress commercial vehicle applications. |
Frequently Asked Questions About Autoshield NP60
Q: Why is the 1-hour drive-away time so critical from an engineering perspective?
A: The 1-hour drive-away time, validated by the FMVSS 212 crash test, signifies that the adhesive has achieved sufficient cohesive strength and modulus to safely restrain the windscreen during a collision. This ensures correct airbag functionality and maintains the structural integrity of the passenger safety cell. It's not just about speed; it's a certified measure of performance under critical load.
Q: Can I really use this without a primer? What's the risk?
A: Autoshield NP60 is engineered for primerless adhesion specifically to clean, abraded automotive ceramic frit bands. It is not primerless on plain glass, which requires the specified Activator and Primer. The risk of omitting the required surface preparation is adhesion failure, as the adhesive cannot form a proper chemical bond to an unprepared or contaminated substrate, compromising the entire installation.
Q: What actually happens if I apply NP60 in 10°C weather?
A: At 10°C, the moisture-curing reaction slows significantly. While the product can be applied down to 5°C, the skin formation time and the time to reach a safe drive-away strength will be at least double the time specified at 23°C. For a safe installation, you must extend the cure time accordingly; the 1-hour drive-away is only valid at 23°C / 50% RH.
Q: The TDS mentions "high modulus." What does this mean for the vehicle?
A: "High modulus" means the cured adhesive is very stiff and resistant to deformation under load. For a vehicle, this is crucial. A high modulus adhesive makes the windscreen a true structural component, restoring the car's original torsional rigidity. This improves handling, reduces squeaks and rattles, and is essential for the proper function of the vehicle's safety systems.
Applications & Core Benefits
| Application / Use Case | Key Benefit | Primary Trades |
|---|---|---|
| Windscreen Replacement (Dual Airbags) | Certified 1-Hour Safe Drive-Away Time (FMVSS 212) | Automotive Glaziers |
| Structural Bonding of Glass to Aluminium | High modulus (>3.5 MPa shear strength) restores vehicle rigidity. | Auto Body Repairers, Specialty Vehicle Builders |
| Fixed Side Glass Installation | High green strength prevents glass slumping, speeding up reassembly. | Automotive Technicians, Glaziers |
| High Vibration Environments (e.g., commercial vehicles) | Exceptional elongation (>700%) absorbs vibration and impacts. | Fleet Maintenance, Bus & Coach Builders |
| Rapid Return-to-Service Repairs | Fastest possible safe cure time increases workshop throughput. | Automotive Repair Shops, Fleet Operators |
Applying Autoshield NP60: Protocols & Best Practices
General Application Steps:- Preparation: Ensure substrate is clean, dry, and prepared precisely as per the Adhesion & Preparation Guide. Ensure sealant and substrates are within the recommended application temperature range (5°C to 35°C).
- Application: Cut the nozzle to produce a triangular bead of the appropriate size. Apply with a steady, consistent pressure using a professional-grade caulking gun, ensuring a continuous, unbroken bead.
- Tooling & Finishing: No tooling is typically required. Position and press the glass into the adhesive within the 20-35 minute skinning time to ensure proper wet-out and contact with the bond line.
- Curing: The vehicle can be safely driven away after 1 hour at 23°C / 50% RH. Protect the bond from significant water exposure until fully cured (approx. 3mm per 24 hours).
For Automotive Technicians: Side Glass Bonding
The Engineering Challenge: Bonding a fixed side glass panel (e.g., quarter glass) where clamps are difficult to apply and rapid handling strength is needed to continue reassembly of the vehicle's interior trim.
The System-Based Solution with Autoshield NP60: The high green strength of Autoshield NP60 is a key advantage here. It develops initial grab very quickly, which helps to hold the glass in place with minimal taping or support, preventing it from sliding or moving while the adhesive cures. The rapid cure profile means interior components can be reinstalled sooner, improving overall job efficiency.
Best Practice Note: Ensure the old sealant bed is mechanically trimmed back to a uniform layer of 1-2mm. Never remove it completely, as this provides an ideal surface for the new adhesive to bond to. Do not clean the old sealant with any alcohol-based products.
Limitations & Safety Protocols
Limitations:- Do not apply at temperatures below 5°C. In lower temperature ranges (5°C to 15°C), all cure and drying times must be doubled.
- Do not apply in the presence of, or in direct contact with, cured or uncured silicone or hybrid (MS, SPUR, STPE) sealants, as this will inhibit the cure and compromise the bond.
- Not suitable for use on substrates where bleed-through may be an issue (e.g., natural stone).
- The product is moisture-curing; opened cartridges must be used promptly and cannot be stored for long periods.
- PPE: Wear protective gloves (nitrile rubber recommended), safety glasses, and suitable protective clothing.
- Ventilation: Use with adequate ventilation. If inhalation risk exists due to atomisation or heating, wear an organic vapour/particulate respirator meeting AS/NZS 1715 & 1716 standards.
- Handling: This product contains isocyanates (MDI) and is a respiratory sensitiser. Avoid inhaling fumes or vapours. May cause allergy or asthma symptoms or breathing difficulties if inhaled. Causes skin and serious eye irritation.
- First Aid: For eye contact, rinse cautiously with water for several minutes. If on skin, wash with plenty of soap and water. If inhaled and breathing is difficult, remove to fresh air. Seek medical advice if symptoms persist.
Autoshield NP60 Adhesion & Preparation Guide
- Ceramic Frit Band: Abrade the bond area with a red Scotch Brite pad (Very Fine) using 5 back-and-forth movements to remove surface contaminants. Clean the surface in a single pass with a lint-free cloth dampened with acetone and allow to flash off. Do not touch the prepared surface. - Primer: No primer required after this preparation.
- Plain Glass (No Ceramic Band): Clean the glass with a suitable glass cleaner. Apply Autoshield Activator using the "wipe on/wipe off" method with a clean, lint-free cloth. Within 30-60 seconds, apply a thin, uniform film of Autoshield GB Primer with an applicator pad. - Primer: Autoshield GB Primer is mandatory. Allow 15-60 minutes dry time before applying sealant.
- Aluminium Body Panels: Ensure surface is clean, dry, and free from oils or grease. Lightly abrade the surface to create a mechanical key. Clean with acetone. Adhesion testing is recommended. - Primer: Adhesion testing is recommended to determine if priming is required.
