For equipment exposed to severe wear in mines, ball mills, coal-fired plants, dredging operations, and abrasive slurry pumps, Megadure Ceramic provides a high alumina bead epoxy lining to protect critical metal, steel, and concrete surfaces from extreme abrasion.
Megadure Ceramic is a two-component, gap-filling epoxy paste formulated with high alumina beads to resist intense abrasive wear. Applied by trowel or spatula, it fills gaps, builds a protective barrier on high-wear steel surfaces, and serves as a high-strength grout between wear-resistant high alumina ceramic tiles and pipe fittings. The system cures under ambient conditions to a distinct green colour, confirming a complete cure and indicating that the surface is ready for service.
This lining system is formulated for protecting industrial bulk handling and processing equipment, including:
To prevent adhesive failure and ensure the lining withstands mechanical stress, prepare substrates according to these minimum specifications:
Megadure Ceramic is engineered for extreme abrasion resistance in heavy industries. This includes protecting equipment in mines, ball mills, coal-fired plants, dredging operations, and abrasive slurry pumps.
Metal surfaces must be grit blasted to AS CK 9.4 Class 3 finish for optimal adhesion. If grit blasting is not possible, mechanically abrade to a clean, bright metal surface and degrease thoroughly. Wire brushing is not sufficient.
At 25°C, the fast-setting Megadure Ceramic has a 10-minute work time and achieves initial cure in 2 hours. The standard-setting version offers 30 minutes of work time, with initial cure in 6 hours. Both require a minimum application temperature of 10°C.
No, the minimum application temperature for Megadure Ceramic is 10°C. Applying below this temperature may compromise proper curing and performance, leading to poor physical properties and reduced abrasion resistance.
| Application | Key benefit | Primary trades |
|---|---|---|
| Lining and protection in mines | Extends equipment service life in severe abrasive conditions, reduces downtime. | Mining contractors, industrial maintenance |
| Wear protection in ball mills and coal-fired plants | Resists continuous impact and abrasion, preventing premature wear and failure. | Power generation, heavy industrial maintenance |
| Protection for abrasive slurry pumps and dredging equipment | High alumina beads counter erosive wear from high-velocity slurries. | Dredging operators, pump service technicians |
| Grouting high alumina ceramic wear tiles | Provides a strong, gap-filling, wear-resistant bond between ceramic tiles and steel surfaces. | Specialised applicators, fabrication workshops |
| Bulk handling and processing equipment lining | Shields surfaces from constant friction and impact in material transfer systems. | Manufacturing, logistics, bulk handling facilities |
Danger: This product causes severe skin burns, serious eye damage, and may cause an allergic skin reaction. Harmful if swallowed or in contact with skin. It is toxic to aquatic life with long-lasting effects. Avoid breathing dust, fume, gas, mist, vapours, or spray.
Wear safety shoes, protective gloves (nitrile rubber recommended), safety glasses or face protection, and suitable respiratory protection. Contaminated work clothing must not leave the workplace. Wash hands thoroughly after handling and before eating, drinking, or smoking.
Natural ventilation is adequate under normal use. Ensure adequate ventilation to avoid inhalation of vapours or dust, especially during mixing or in confined spaces. If inhalation is unavoidable, wear suitable respiratory protection.
Store in a cool, dry, well-ventilated place, out of direct sunlight, and away from foodstuffs and incompatible materials. Keep containers closed and standing upright. Store locked up. Dispose of contents and container in accordance with local, regional, national, and international regulations. This material is a Scheduled Poison (S5, Caution) and is classified as Dangerous Goods for transport (Class 9 for Part A, Class 8 for Part B).
Proper surface preparation is critical for Megadure Ceramic to achieve its documented adhesion and wear resistance. Incomplete preparation compromises performance and product longevity.
Surface prep: Grit blast to AS CK 9.4 Class 3 finish. If grit blasting is not possible, mechanically abrade to a clean, bright metal surface. Follow with degreasing using a proprietary degreaser. Wire brushing is not recommended as it provides minimal adhesion only.
Primer: Not required. The epoxy paste adheres directly to properly prepared metal.
Surface prep: Remove all grease, oil, and surface laitance. Clean with an industrial heavy-duty degreaser if needed. Mechanically abrade surfaces via scabbling, grit blasting, or grinding. Concrete must be completely dry and free of loose particles, dust, and dirt for maximum adhesion.
Primer: Not required. The epoxy paste adheres directly to properly prepared concrete.
Surface prep: Remove all existing paint. For painted metal, follow the grit blasting or mechanical abrasion process described for metals. For painted concrete, flame clean or mechanically treat (grinding, scabbling, shot blasting, or scarifying) to remove all paint traces, then follow the concrete preparation steps.
Primer: Not required after complete removal of paint and proper substrate preparation.
| Property | Value |
|---|---|
| Product Type | Two-Component Gap-Filling Epoxy Paste |
| Formulation | High Alumina Bead, Wear-Resistant Lining |
| Colours (Cured) | Green |
| Available Formulations | Standard Setting, Fast Setting |
| Packaging | 2 kg kit |
| Kit Yield | 0.5 m² at 2mm thickness (per 2 kg kit) |
| Minimum Application Temperature | 10°C |
| Work Time (Standard Set) @25°C | 30 minutes |
| Work Time (Standard Set) @15°C | 60 minutes |
| Work Time (Quick Set) @25°C | 10 minutes |
| Work Time (Quick Set) @15°C | 20 minutes |
| Initial Cure (Standard Set) @25°C | 6 hours |
| Initial Cure (Standard Set) @15°C | 12 hours |
| Initial Cure (Quick Set) @25°C | 2 hours |
| Initial Cure (Quick Set) @15°C | 4 hours |
| Full Cure (Standard Set) @25°C | 24 hours |
| Full Cure (Standard Set) @15°C | 48 hours |
| Full Cure (Quick Set) @25°C | 12 hours |
| Full Cure (Quick Set) @15°C | 24 hours |
| Part A Form | Paste |
| Part A Colour | White |
| Part A Solubility | Insoluble in water |
| Part A Specific Gravity @25°C | 2.00-2.06 |
| Part A Vapour Pressure @20°C | <0.01 Pa |
| Part A Flash Point | >200 °C |
| Part A Boiling Point/Range | >200 °C |
| Part A Decomposition Point | >200 °C |
| Part A Total VOC | Nil (0 g/L) |
| Part B Form | Liquid |
| Part B Colour | Blue |
| Part B Odour | Amine |
| Part B Solubility | Soluble in Water |
| Part B Specific Gravity @25°C | 0.98-1.02 |
| Part B Vapour Pressure @20°C | <0.01 kPa |
| Part B Flash Point | 149 °C |
| Part B Boiling Point/Range | 277 °C |
| Part B Decomposition Point | >200 °C |
| Part B Total VOC | Nil (0 g/L) |
| Dangerous Goods Class (Part A) | 9 |
| Hazchem Code (Part A) | •3Z |
| Dangerous Goods Class (Part B) | 8 |
| Hazchem Code (Part B) | 2X |
| Poison Schedule | S5. Caution |
