Autoshield GB Autoglass Primer

Black autoglass primer for UV-blocking windscreen bond lines and suitable pinchweld touch-ups in compatible polyurethane glazing systems. Use the adhesive's specified drying window.

Vendor: Adheseal
SKU: PRIMEGB/250
Availability: In Stock
$56.25
$56.25
Prices do not include GST
Guaranteed safe checkout
  • Apple Pay
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa
  • Secure SSL encrypted checkout
  • Fast, tracked shipping
  • Easy returns & support
Shipping & Delivery

Flat-rate shipping $17.95 + GST (metro and standard zones). Excludes remote/regional/high-cost postcodes and certain items (DG, oversized, long-length, or bagged products 15 kg+). If your order includes any of these, we will contact you to arrange additional freight charges. Online purchases only.

Download Product Data

Download TDS Download SDS
Description

Autoshield GB Autoglass Primer is a black automotive glazing primer used to prepare compatible glass and vehicle bond surfaces for polyurethane windscreen adhesive. Its opaque film helps shield exposed polyurethane bond lines from UV and is used in suitable pinchweld repair details.

Choose GB Primer when the glazing system specifically requires a black primer or UV blockout layer. It is distinct from Autoshield Activator, a clear surface-treatment wipe. Neither product replaces the adhesive itself or a complete approved windscreen replacement procedure.

Typical uses

  • Plain-glass windscreen bonding: providing the specified black bond-line preparation where the glass lacks a suitable ceramic band.
  • Pinchweld repair details: treating appropriate scratches or chips in the prepared vehicle bond area, subject to the vehicle repair procedure.
  • Polyurethane autoglass systems: promoting adhesion at compatible glazing interfaces after the designated cleaning and activation steps.

Application and compatibility

Work on clean, dry, grease-free substrates and apply a thin, continuous film with a suitable applicator. Follow the adhesive system's exact flash-off and overcoating requirements. With Autoshield NP-60, the associated installation instructions specify a 15–60 minute primer drying window, with additional allowance in colder conditions.

This is a solvent-containing professional glazing preparation product. Avoid incompatible plastics and uncured films; keep the container sealed and use appropriate ventilation and PPE. Vehicle glazing performance and safe drive-away depend on the entire approved system and installation conditions.

Common Questions

What is Autoshield GB Primer used for?
It primes automotive glass and compatible body bond surfaces before Autoshield 1-FC polyurethane adhesive.

How long should it flash off?
Allow at least about 10 minutes above 5°C and follow the current TDS for the permitted maximum open time.

What coverage should I allow?
About 50ml/m².

Why is the primer fluorescent?
The luminescent agent helps installers check primer coverage under long-wave UV light.

Uses & Benefits
Black solvent-based polyurethane primer for direct automotive glazing with Adheseal Autoshield 1-FC. Promotes adhesion and provides UV blockout at the bond line. Contains a luminescent agent that assists coverage checking under long-wave UV light. Application temperature is 5°C to 40°C. Coverage is about 50ml/m² and flash-off is at least about 10 minutes above 5°C before adhesive installation.
How To Apply
Prepare glass and body bond faces so they are dry and free from oil, grease, dust and contamination. Shake or mix the primer as required by the current TDS before use. Apply a thin continuous coat by brush, felt or foam applicator at about 50ml/m². Allow the required flash-off, at least about 10 minutes above 5°C. Check coverage where required using the primer's long-wave UV fluorescence, then apply Autoshield 1-FC within the permitted open time.
Limitations and Safety Info
Use only on clean, dry and properly prepared glazing and vehicle-body bond surfaces. Do not apply outside the 5°C to 40°C application range. Do not leave the primed surface exposed to contamination before adhesive application. Follow the current TDS for the maximum open period after priming. Use the current SDS for solvent and flammability controls.
Suitable Substrates
  • Automotive float glass.
  • Ceramic-coated automotive glass.
  • Prepared painted and pre-coated vehicle body surfaces.
  • Compatible prepared metals and plastics used in direct glazing systems.

Autoshield GB Autoglass Primer Physical Properties

Autoshield GB Autoglass Primer Physical Properties
Property Value
Base Chemistry Solvent Based Polyurethane solution
Solid Content 27 %
Application Temperature 5 – 40 °C (ideal 15 – 25 °C)
Coverage 50 ml/m²
Recoat Time Above 5 °C: 10 minutes maximum; up to 24 hours depending on temperature
Shelf Life 18 months (≤ 25 °C, sealed container)
Form Liquid
Odour Solvent like
Density 0.95 g/cm³
Vapour Pressure (20 °C) 105 hPa
Flash Point -8 °C
Autoignition Temperature >200 °C
Boiling Point/Range 79 °C
Viscosity approx. 50 mPas
UN Number 1866
Packing Group II
Hazchem Code •3YE
Marine Pollutant Yes

Autoshield GB Autoglass Primer - Use Cases

Here are some common examples on where Autoshield GB Autoglass Primer used by our customers.

Auto Glass

Auto Glass Direct Glazing Prep

Preparing windscreens or automotive glass for structural bonding with Autoshield 1-FC polyurethane.

Creates a robust linking layer for Autoshield 1-FC PU, ensuring strong, durable adhesion on diverse automotive glass types.

  • For Autoshield 1-FC PU adhesive
  • Bonds float glass, ceramic-coated glass
  • Black colour for UV blockout
  • Step 2 in 3-step system

Auto Body

Primer Application Quality Check

Needing to visually verify 100% primer coverage on automotive bond faces during critical applications.

Its UV fluorescence allows instant, visible confirmation of complete coverage, minimizing application errors and ensuring quality control.

  • Visible under UV light (320-420 nm)
  • In-process coverage control
  • Black primer, 27 % solid content
  • Flash-off time 10 minutes (above 5 °C)

Auto Body

Automotive Panel Structural Bonding

Structurally bonding Autoshield 1-FC polyurethane adhesive to painted vehicle panels and E-coats.

Enhances adhesion between Autoshield 1-FC PU and varied body coatings, crucial for durable, high-strength automotive assembly.

  • For Autoshield 1-FC PU adhesive
  • Bonds painted surfaces, E-coats
  • Solvent-Based Polyurethane solution
  • Application temperature 5 – 40 °C

Auto Glass

Verify Primer Coverage UV

Confirming uniform primer application and presence during windscreen replacement quality control checks.

Its UV-fluorescent property enables quick, non-destructive visual inspection of primer coverage, crucial for in-process quality assurance.

  • UV light 320-420 nm
  • in-process control
  • 50 ml/m² coverage
  • moisture reactive system

Caravan & Truck

Direct Glazing Mixed Substrates

Bonding new windscreens to diverse vehicle surfaces like painted metal, E-coats, or plastics.

Specifically formulated for Autoshield NP-60, it ensures consistent, strong adhesion across various automotive substrates, including factory finishes.

  • E-coats
  • painted surfaces
  • ceramic-coated glass
  • application 5-40 °C
